Working on a remote server

Learning Objectives

In this lesson, you will learn:

How to connect to a remote server
Get familiar with RStudio server
Get an introduction to the command line (CLI) & bash

Why working on a remote machine?

Often the main motivation is to scale your analysis beyond what a personal computer can handle. R being pretty memory intensive, moving to a server often provides you more RAM and thus allows to load larger data in R without the need of slicing your data into chunks. But there are also other advantages, here are the main for scientist:

Power: More CPUs/Cores (24/32/48), More RAM (256/384GB)
Capacity: More disk space and generally faster storage (in highly optimized RAID arrays)
Security: Data are spread across multiple drives and have nightly backups
Collaboration: shared folders for code, data, and other materials; same software versions

Warning

=> The operating system is more likely going to be Linux!!

Introduction to UNIX and its siblings

UNIX: Originally developed at AT&T / Bell Labs circa 1970. Has experienced a long, multi-branched evolutionary path
POSIX (Portable Operating System Interface): a set of specifications of what an OS needs to qualify as “a Unix”, to enhance interoperability among all the “Unix” variants

Various Unices

Linux (Linus Torvalds, 1991)

is not fully POSIX-compliant, but certainly can be regarded as functionally Unix
Some popular Linux distributions include Debian, Fedora Linux, Arch Linux, and Ubuntu. There are also commercial distributions such as Red Hat Enterprise Linux and SUSE Linux Enterprise. Android is actually Linux-based!
OS X

is a Unix!

Some Unix hallmarks

Supports multi-users, multi-processes
Highly modular: many small tools that do one thing well, and can be combined
Culture of text files and streams
Primary OS on HPC (High Performance Computing Systems)
Main OS on which Internet was built

Connecting via IDE - Posit Workbench

From an user perspective, Posit Workbench is your familiar RStudio interface in your web browser. The big difference however is that with RStudio Server the computation will be running on the remote machine instead of your local personal computer. This also means that the files you are seeing through the RStudio Server interface are located on the remote machine. And this also include your R packages!!! This remote file management is the main change you will have to adopt in your workflow.

To help with remote files management, the RStudio Server interface as few additional features that we will be discussing in the following sections.

Connecting to MEDS Analytical Server

Reference

MEDS computational servers guide

Got to: https://workbench-1.bren.ucsb.edu
Enter your credentials
You are in!

Click on the New Session button. You can see that you are able to start both an R (Studio) and jupyter notebook session. Let’s take a few minutes to experiment with the different options.

For this session, we are going to select the RStudio option and hit Start Session.

You should now see a very familiar interface :) Except it is running on the server with a lot of resources at your fingertips!!

File structure

Let’s explore explore a little bit the file structure on the server. By default on a Linux server, you are located in the home folder. This folder is only accessible to you and it is where you can store your personal files on a server. You should see 2 folders: R and H

The R folder is where your local R packages will be installed, you can ignore it. The H is your H drive that the Bren School is offering to all its students. If you click on it you should see any files you have uploaded there.

Let us make a folder named github by click on the New Folder button at the top of the tab. We will use this folder (also named directory in linux/unix terms) to clone any GitHub repository.

R packages

If we go to the Packages tab, we can see a long list of packages that have already be installed by our system administrator (Brad). Those packages have been installed server wide, meaning that all the users have access to them.

A user can also installed her/his own packages. Let’s try to install the remote package that lets you install R packages directly from GitHub: install.packages("remotes"). Once done, note a new section that appeared on the Packages tab named User Library. Each of us have now its own copy of the package installed (in this R folder we were talking about a few minutes ago).

A few notes:

In this example we will have made a better choice to have the remotes package installed once at the system level
Some R packages depend on external libraries that need to be installed on the server. Those libraries will have to be installed by the system administrator first before you can install the R package
Installing an R package on a linux machine generally requires compilation of the code and will thus take more time to install than when you install it from pre-compiled binaries

Look now inside you R folder!!
